Description
Proto J5552HL Includes
- (1) 3/4" DRIVE DEEP SOCKET 1-5/8" - 6 POINT
Proto J5552HL Features
- Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
- The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
- The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
- The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
- Made from alloy steel.
- Heat-treated for strength and durability.
- Hand use only.
- Ball detent design.
Proto J5552HL Specifications
SIZE | 1-5/8" |
NUT END OUTSIDE DIAMETER | 2-1/4" |
DRIVE END OUTSIDE DIAMETER | 1-3/4" |
NUT DEPTH | 1-7/64" |
BOLT CLEARANCE DEPTH | 2-13/64" |
OVERALL LENGTH | 3-1/2" |
WEIGHT | 1.52 lbs |
DRIVE SIZE | 3/4" |
POINT SIZE | 6 |
FINISH | Satin |
LENGTH TYPE | Deep |
UNIT OF MEASURE | Fractional |
SPECIFICATION ASME | ASME B107.110-2012 |
SPECIFICATION AS | SAE AS4984A |
