Description
Proto J10014S Includes
- (1) 1" DRIVE IMPACT SOCKET 7/8" - 8 POINT
Proto J10014S Features
- Drive end chamfer and four detents help provide quick positive engagement with drive tool on any of the socket drive walls.
- Tight tolerances for snug fit on fastener.
- Large clearance holes, concentric opening and nut end chamfer make it easy to position socket on fasteners.
- Made from high-strength steel to help minimize wall thickness and provide access to fasteners in recesses and where nuts and bolts protrude.
- Impact sockets are used wherever powered drive tools are used to install or remove fasteners.
- Impact sockets are designed to withstand the high torque and force associated with impact tools in repetitive application.
- Features two through holes and a groove to accept a Proto® Retaining Ring or pin and O-ring to help secure the socket to the drive tool anvil.
Proto J10014S Specifications
SIZE | 7/8" |
NUT END OUTSIDE DIAMETER | 2" |
DRIVE END OUTSIDE DIAMETER | 2" |
NUT DEPTH | 5/8" |
BOLT CLEARANCE DEPTH | 1-3/8" |
OVERALL LENGTH | 2-5/8" |
WEIGHT | 1.33 lbs |
CRUSH RETAINING RING | JRR10028 |
O-RING | J10000R1 |
RETAINING PIN | J10000P1 |
DRIVE SIZE | 1" |
POINT SIZE | 8 |
FINISH | Black Oxide |
LENGTH TYPE | Standard |
UNIT OF MEASURE | Fractional |
